1.7 Inch 128 * 64 Lcd Display Dot Matrix FSTN COG LCD Module ST7567

1.7 Inch 128 * 64 Lcd Display Dot Matrix FSTN COG LCD Module ST7567

Brand Name:	Enrich
Model Number:	ENH-DG128064-315
MOQ:	2000 pcs
Price:	$1.50-$10.00
Payment Terms:	T/T

Detail Information

Product Description

Ratings & Reviews

Detail Information

Place of Origin:

China

Certification:

Rohs，ISO9001

Size:

1.7 Inch

Display Mode:

FSTN/Transflective/Positive

Viewing Angle:

6 0'clock

Drive IC:

: ST7567

Highlight:

1.7 Inch graphic display module

ST7567 graphic display module

ST7567 128 * 64 Lcd Display

Product Description

Custom 128x64 Dot Matrix FSTN COG Graphic Monochrome LCD Display Module

Product Specifications

Size	1.7 Inch
Display Mode	FSTN/Transflective/Positive
Viewing Angle	6 0'clock
Drive IC	ST7567

Display Mode: FSTN/Transflective/Positive
Viewing Angle: 6 0'clock
Drive Method: 1/64 Duty, 1/9 Bias, Vop=9.0V, Vdd=3.0V
Operating Temperature: -20°C ~ +70°C
Storage Temperature: -30°C ~ +80°C
Connector: COG+FPC
Drive IC: ST7567
Backlight: White, IF=30mA, VF=3.0V±0.2V

Primary Application Areas

Industrial Control

Equipment status display

Instrumentation panels

Consumer Electronics

Portable device displays

Home appliance interfaces

Medical Devices

Portable medical instruments

Basic diagnostic devices

Transportation Systems

Shared device lock screens

In-vehicle information terminals

Retail & Payment

POS systems

Electronic shelf labels

Communication Devices

Walkie-talkie status screens

Network equipment indicators
